The self-priming diesel engine pump uses a diesel engine as a driving device, combines self-priming and non-clogging sewage discharge, and then uses the unique design of the pump body and impeller flow channel to make it operate normally, and does not require the installation of a bottom valve and water diversion when in use.
Since the self-priming diesel engine pump can absorb and discharge liquids containing large solid particles and long fiber impurities, it is suitable for municipal sewage and flood control projects, agricultural irrigation, etc.
The self-priming diesel engine pump produced by Weifang Sunny Machinery Co., Ltd. has the characteristics of simple structure, good self-priming performance, strong sewage discharge capacity, high efficiency and energy saving, easy use and maintenance, integrated or outdoor movable design.
Use conditions of self-priming diesel engine pump
1) Ambient temperature ≤50℃, medium temperature ≤80℃, special requirements can reach 200℃.
2) Medium PH value: cast iron material is 6-9, stainless steel is 2-13.
3) Medium weight does not exceed 1240kg/m³
4) The self-priming height cannot exceed 4.5-5.5 meters, and the length of the suction pipe is ≤10 meters.
Standard scope of supply of the unit
1) Self-priming diesel engine pump: diesel engine, water pump, coupling, cooling fan, radiator water tank, steel structure base (including engine bottom oil tank 80-120L), battery and connecting wires, exhaust muffler, control panel.
2) The standard design is a composite integrated type of pump group, engine bottom oil tank, control panel, and battery group.
3) According to customer requirements, it can be designed as an outdoor type with a composite integrated type of pump group, engine bottom oil tank, control panel, battery group, and outdoor rainproof box.
4) The base of the pump group can be designed in the form of a trailer, which can be matched with four-wheel or two-wheel styles according to customer requirements.
Ordering instructions for self-priming diesel engine pumps
1. When purchasing a unit, you first need to tell us your requirements so that we can choose the right model for you. For example:
① Product name and self-priming diesel engine pump model
② Self-priming diesel engine pump caliber
③ Self-priming diesel engine pump head (m)
④ Self-priming diesel engine pump flow
⑤ Self-priming diesel engine pump motor power (KW)
⑥ Self-priming diesel engine pump speed (r/min)
⑦ Self-priming diesel engine pump voltage [V]
⑧ Self-priming diesel engine pump suction head (m)
⑨ Whether the self-priming diesel engine pump comes with accessories
2. When the use occasion is very important or the environment is relatively complex, please try to provide design drawings and detailed parameters, and our technical experts will review and check for you.
