There are more and more tractors widely use in world farms. So there are more and more diesel engines, single cylinder or multi cylinders, are good backup power in farmers warehouse. Irrigation water pumps are essential role in farm irrigation and dewatering requirements. Mostly those are installed with one diesel engine driving water pump, surely those are main products in our factory. We have production of tractor driving water pump, specialized coupling with tractor flying wheel by pulley or rear output by splined shaft, which can raise the usage frequency of your tractors, surely saving money. .
Sample mode
|
Diesel engine model |
60HP Tractor |
|
Diesel engine power (KW) |
44 |
|
Cylinder No. |
4 |
|
Water pump model |
350HW1000-8 |
|
Rotation speed (RPM) |
980 |
|
Suction diameter (inch) |
14 |
|
Outlet diameter(inch) |
14 |
|
Outflow rate (m3/h) |
1000 |
|
Head lift (m) |
8 |
|
Suction lift(m) |
5 |
Working scope
Diameter: 150-500mm
Outflow : 200-2500m3/h
Head lift: 3-40m
Engine power: 15-200KW
Rotation speed: 750/980/l500/1800/3000r/min
Features
a. Compact structure, reasonable design, powerful functions, easy in use
b. Strong connection unit makes it easy in use and reliable.
c. The flexible connection coupling can protect the engine shaft.
d. The tractor driving water pump can be equipped with trailer, priming water unit, hose, pipe fitting, valve optional.
